Bently Nevada 3500/91 161204-01 EGD Communication Gateway Module

The Bently Nevada 3500/91 161204-01 EGD communication gateway module is a device that plays a key role in the Bently Nevada monitoring system. The following is a detailed introduction to the module:

Product Overview:

The 3500/91 161204-01 EGD communication gateway module is a core component in the Bently Nevada monitoring system, designed to meet the needs of various industrial applications.

It has high reliability, high performance, high flexibility and other characteristics, ensuring stable and effective operation in various environments.

Main functions:

Monitoring and communication: This module is mainly used to monitor mechanical protection and can communicate and control various devices (such as controllers, sensors and actuators).

Data processing and storage: This module has powerful data processing and storage capabilities and can handle various complex data and algorithms.

Communication Protocol Support: Supports multiple communication protocols, including EGD (version 2.01) Ethernet UDP/IP, IEEE802.3 10BASE-T and 100BASE-TX (twisted pair), and IEEE 802.3u (fiber optics).

Technical Features:

Ethernet Global Data (EGD) Communication Gateway Function: Provides integration with EGD protocol compatible controllers, such as GE Mark* VIe controllers.

Rack Monitoring: Collects static data and sends the data to the information system at pre-selected time intervals, enabling integration with process control and other automation systems (such as DCS, PLC or HMI).

Interfaces and Connectivity: Provides a wide range of serial (RS232/RS422/RS485) and Ethernet TCP/IP communication functions to ensure seamless connection with various systems.
