138607-01 Bently Nevada 3500/22M Standard Transient Data Interface Module

The details of the 138607-01 Bently Nevada 3500/22M Standard Transient Data Interface Module are as follows:

I. Product Overview

The Bently Nevada 3500/22M 138607-01 Transient Data Interface (TDI) is a product provided by Bently Nevada (also known as GE Industrial Solutions). It is an interface between the 3500 monitoring system and compatible software (such as System 1 Condition Monitoring and Diagnostic Software and 3500 System Configuration Software).

II. Main Features

Data Acquisition: It can continuously acquire steady-state and transient waveform data, which is very useful for analyzing the operating status of mechanical equipment and diagnosing potential problems.

High-speed data transmission: Through Ethernet connection, the collected data can be quickly transferred to the host computer software to ensure the real-time and accuracy of the data.

Compatibility and scalability: Compatible with the 3500 monitoring system and Bently System 1TM machinery management software, it can be easily integrated into existing industrial automation systems.

Integrated functions: Combines the functions of the 3500/20 rack interface module (RIM) and the data collection functions of communication processors such as TDXnet.

Wide application: Can be connected with M series monitors (such as 3500/40M, 3500/42M, etc.) to provide key data for monitoring and diagnosis of various rotating equipment.

Capture dynamic and high-resolution data: With the optional channel enable disk, it is possible to capture dynamic and high-resolution transient data.

III. Technical specifications

Supports USB-B interface, 10Base-T or 100Base-TX Ethernet (adaptive), and 100Base-FX fiber optic Ethernet.

Has a rack reset button, pre-alarm and post-alarm data LED indicators, and I/O module relays.

Control pulse function: Although it is mainly used as a data interface module, it also has the function of controlling pulse signal generation and processing for pulse control and counting applications in industrial automation systems.

IV. I/O module design

The TDI I/O module has a 2-pin connector for connecting the signal common end to the single-point instrument ground of the rack.

5. Key signal input

Supports four 3500 system key signals.

6. Summary

Bently Nevada 3500/22M 138607-01 transient data interface module is an indispensable part of industrial automation and mechanical equipment monitoring. It helps enterprises achieve efficient and reliable equipment operation and maintenance by providing accurate and real-time data.
