NI PXIE-4300 8-channel isolated analog input module
Delivery time 3 days
Product origin New/used
Email plcru@foxmail.com
Mobile/wechat /WhatsApp +86 18185397189
The NI PXIE-4300 8-channel isolated analog Input module is a high-performance da
The NI PXIE-4300 8-channel isolated analog Input module is a high-performance data acquisition device manufactured by National Instruments (NI). The following is a detailed analysis of the module:
I. Product overview
Make and Model: PXIE-4300 produced by NI Corporation.
Number of channels: 8 channels.
Isolation: This module provides isolation between channels, which is one of its important features, ensuring accurate measurements in high pressure or high noise environments.
Application: Widely used in electronics, aerospace, automotive, electrical and other fields, especially suitable for the measurement system requiring high precision, high isolation and synchronous sampling capability.
2. Technical specifications
Resolution: 16 bits, which means that the module is able to capture very fine signal changes.
Sampling rate: Up to 250 kS/s (thousand samples/second), that is, 250,000 samples per second can be collected per channel to meet the needs of high-speed data acquisition.
Voltage range: Supports voltage measurements up to 300 volts, which makes it ideal for high-voltage test environments such as automotive fuel cell and battery pack testing.
Data transmission rate: The data transmission rate of each module can reach 4MB/s, and a single chassis can reach 68MB/s, ensuring efficient data transmission capacity.
Three, functional characteristics
High accuracy: The advanced analog-to-digital converter (ADC) and built-in signal conditioning function ensure the accuracy of measurement results.
Synchronous sampling: Multi-channel synchronous sampling is supported to ensure the consistency and comparability of data in each channel.
Scalability: It can be extended to 136 channels in a single chassis, and can be extended to thousands of channels when multiple chassis are synchronized, meeting the needs of large-scale testing.
Safety: Provides CAT II channel isolation and voltage resistance to protect users and equipment from dangerous voltages.
