Yokogawa WT1800E High Performance Power Analyzer

The Yokogawa WT1800E High Performance Power Analyzer is an advanced measurement device whose outstanding stability, flexibility and high accuracy make it an ideal choice for inverter driven motors, renewable energy technologies and traction applications such as pumps, fans and hybrids. / electric vehicles, etc.) Ideal tool for efficiency testing.

Key features of this analyzer include:

High accuracy: The power accuracy of WT1800E is extremely high and can reach "0.05% of reading + 0.05% of range". This accuracy is in a leading position among similar power analysis instruments. At the same time, it is able to perform up to 500 harmonic analyzes (50/60Hz fundamental frequency), providing powerful support for complex power system analysis.

Flexibility: WT1800E has up to 6 input channels, wide range display and analysis functions. In addition, it can be connected to a computer, providing users with a wide range of measurement solutions. Its high-resolution 8.4-inch XGA display can browse up to 6 waveforms in split screen and display up to 12 pages of different measurement parameters, greatly improving the convenience of data analysis.

Stability: The WT1800E has extremely high stability, ensuring accurate measurements now and in the future. Its high-resolution display and synchronous measurement function (executed at 2MS/s (16-bit)) make the measurement results more accurate and reliable.

In addition, the WT1800E has a wide voltage and current range, allowing direct input of measurement signals, making it possible to measure extremely small currents that are difficult to measure with current sensors. At the same time, its voltage and current frequency bandwidth reaches 5 MHz (-3 dB typical), which is more than 5 times wider than the previous model, and can capture fast switching signals more accurately.

In general, the Yokogawa WT1800E high-performance power analyzer is a powerful, flexible, and extremely precise measurement device suitable for various complex power system analysis and testing tasks.
