IS230PCAAH1A GE Core Analog Module

IS230PCAAH1A GE Core Analog Module

Basic Information:

Manufacturer: General Electric (GE)

Part Number: IS230PCAAH1A

Country of Manufacture: United States

Product Type: Core Analog Module

Dimensions: 17.71 × 13.77 × 7.87 cm

Operating Temperature: -30 to 65 degrees Celsius

Series: Mark VIe

Features:

Applicability: This module is a core analog module designed for the Mark VIe system, especially for gas turbine control.

Analog Signal I/O: Most of the analog signal I/O required for gas turbine operation is provided by the core analog (PCAA) module and the associated core analog (TCAS and TCAT) terminal board.

Input and Output Type: Supports thermocouple inputs, 4-20 mA current loop I/O, seismic inputs, linear variable differential transformer (LVDT) excitation and inputs, pulse rate inputs, and servo coil outputs.

System Compatibility: Applicable to simplex, dual-channel and TMR systems.

Module structure: includes a processor board shared by all Mark VIe distributed I/O boards, two application I/O boards and a terminal board.

Power supply: powered by a 28V DC power connector and two RJ45 Ethernet connectors.

Connectivity: Field device I/O is provided through European box terminals and connected to TCAT through two 68-pin cables.

Installation and connection:

Firmly fix the PCAA module.

Connect the JGPA power connection to the P4 connector of the PCAA.

Use two 68-pin cables to connect the PCAA module to the optional related TCAT terminal board.

Network connection: PR1 and PR2 are connected to the R controller network, PS1 and PS2 are connected to the S controller network, and PT1 and PT2 are connected to the T controller network.

Technology and application:

IS230PCAAH1A is a high-performance and high-reliability gas turbine control module developed by GE. It uses advanced microprocessor technology and digital signal processing technology to quickly respond to various changes and needs of gas turbines and achieve precise control. In addition, the module also has a variety of protection functions to prevent gas turbines from malfunctioning or being damaged under abnormal conditions.

In general, the IS230PCAAH1A GE core simulation module is a powerful, reliable and stable gas turbine control module, which is suitable for various gas turbine control systems and provides strong support for the development of industrial production and energy fields.
