GE IC695CPU315-CD Processor Module

The GE IC695CPU315-CD processor module is a high-performance, versatile central processing unit module designed for industrial automation and control applications. The following is a detailed introduction to the main features and functions of the module:

Processor Performance:

Based on the Celeron M microprocessor, it provides a processing speed of 1.0 Gigahertz, ensuring that the system can handle complex control and data processing tasks efficiently and in real time.

Capable of up to 32K I/O operations per second, supporting up to 512 program blocks, each with a maximum size of 128 KB, it provides powerful computing power for industrial automation and control.

Memory Capacity:

With 20 MB of user memory, it provides ample space for storing user programs, data and system configurations.

Also includes 20 MB of NVRAM to provide a stable storage environment for the system.

32 kb of memory are reserved for discrete I/O and analog I/O respectively, ensuring efficient processing of various input/output operations.

Communication Interface:

Supports high-speed serial communication, including the RX3i PCU bus, making data transmission with other devices or systems faster and more stable.

Two integrated serial ports are provided, one supports RS-232 communication and the other supports RS-485 communication, which is convenient for communication with other devices, sensors and actuators.

Supports multiple serial protocols such as serial I/O, Modbus RTU slave and SNP protocol, which enhances the compatibility of the module with other devices.

Programming and configuration:

Strong programmability, supports C language or IEC (International Electrotechnical Commission) approved ladder logic (ladder diagram), structured text or function block diagram language for programming.

GE's development tools can be used for programming and configuration to meet specific application requirements.

Power supply and hardware protection:

It has power management function, can monitor power supply status and power supply load, and provide power supply fault detection and alarm function.

Equipped with a variety of hardware protection functions, including overcurrent protection, overheating protection, short circuit protection, etc., to ensure the stable operation of the module in complex industrial environments.

Scalability and compatibility:

Supports a variety of expansion functions, such as accessories that can be ordered with the CPU, including IC695ACC302 intelligent auxiliary battery, IC693ACC302 ordinary auxiliary battery, etc., providing users with more choices and flexibility.

Supports automatically located symbolic variables, allowing the use of any amount of user memory.

Complies with PCI standard version 2.2 and supports most GE series 90-30 modules and expansion racks.

Other features:

Supports hot-swap function, which allows the module to be plugged and unplugged while the system is running.

The operating temperature range is 32 to 140 degrees Fahrenheit, suitable for a wide range of industrial environments.

The CPU firmware is field upgradeable, which is convenient for users to maintain and update.

Complies with EU RoHS Directive 2002/95/EC and related exemptions to ensure environmental compliance.

In summary, the GE IC695CPU315-CD processor module is a powerful and high-performance central processor module suitable for a variety of industrial automation and control applications. Its high performance, large memory capacity, high-speed serial communication and multiple communication interfaces make it widely competitive in the market.
