GE FANUC IC670ALG240-JC Analog input module
I. Product overview
Model: IC670ALG240-JC
Brand: GE Fanuc
Type: Analog input module
Function: Receive and process analog current input signal
2. Technical specifications
Input channel:
It has 16 single-ended input channels and can be configured as 0-20 mA or 4-20 mA.
The resolution of each channel is 16 bits, ensuring high precision signal acquisition.
Input signal range:
Support 0-20 mA and 4-20 mA current input signals.
It can operate in the input signal range of 0-25 mA.
Power requirements:
A current loop supply of 20-28 VDC with a nominal ripple voltage of 10% is required.
The maximum current consumption is 251 mA from the Bus Interface Unit (BIU) power supply.
Working environment:
Operating temperature range is 0-55 degrees Celsius.
There is a certain temperature coefficient that affects the accuracy of the signal, but the specific value may vary by model and batch.
Interface and compatibility:
Supports ANSI Type 2 2 - and 3-wire transmitter wiring, as well as ANSI Type 3 670 - wire transmitter wiring configurations.
Designed for mounting along bus interface units (BIUs) and extension racks.
Built-in features:
Comes with a built-in analog-to-digital converter (ADC) for converting analog data to a digital format with a resolution of 16 bits.
Support internal diagnostic functions, such as module calibration is not calibrated, calibration data out of range, calibration writing failure alarm and diagnostic information.
3. Application scenarios
The IC670ALG240-JC module is widely used in the field of industrial automation, especially those requiring high-precision analog current signal input.
It can be used to connect field transmitters such as pressure, level, flow, temperature, turbidity and other sensors, as well as panel meters, data loggers, single loop controllers, variable frequency drivers (VFDS), signal splitters, signal isolators and other devices.
