GE FANUC PCI-5565RC Reflective memory node card

The GE FANUC PCI-5565RC Reflective Memory Node card is a PCI Express (PCIe) product in Abaco's family of Reflective memory real-time fiber optic networking products, featuring high speed, flexibility and ease of operation. Here is a detailed description of the product:

I. Product overview

Product name: GE FANUC PCI-5565RC Reflective memory node card

Series ownership: Abaco reflective memory real-time fiber network product line

Main interface: PCI Express

Application scenario: It is suitable for distributed systems requiring high-speed and real-time data sharing, such as data acquisition, simulation and training, industrial automation, and electronic communication.

Second, functional characteristics

High speed connection

Serial connection speed: 2.12 Gbaud

Data transfer rate: up to 170 Mbyte/s

Packet size: Support for dynamic packet sizes from 4 to 64 bytes

Low latency

Deterministic transfer rate: Latency between nodes is only 450 to 500 nanoseconds

High reliability

Error management and detection: prevents data loss

Redundancy mode: Optional redundancy mode improves system reliability

Flexibility and extensibility

Number of nodes: Supports a maximum of 256 nodes

Fiber support: Support up to 300 meters of multi-mode fiber and up to 10 kilometers of single-mode fiber

Configuration: Star configuration can be performed using the AC-5595 hosted hub

Memory and storage

On-board SDRAM: Provides 128/256 MB of reflected memory with optional parity

Independent DMA channel: Has a separate direct memory access (DMA) channel

Operating system support

Supports the Windows 2000, Windows XP, Linux, and VxWorks operating systems

3. Technical specifications

Interface standard: Complies with PCI Express 1.0a standard

Onboard resources: x4 channel PCI Express bridge, four universal network interrupts (each with 32-bit data)

Configuration options: Configurable end conversion, suitable for multiple CPU architectures on the same network; PCI PIO window sizes can be selected, from 2 MB bytes to 64 MB bytes to the full installed memory size

4. Application advantages

Bus-independent design: Protecting current network infrastructure investments

High Performance application deployment: Low latency, deterministic data transfer rates enable predictable high performance application deployment

Seamless integration: Seamless integration with GE Fanuc Intelligent Platforms' SBC solutions and most industry standard products

5. Use and maintenance

Hardware installation: Insert the reflective memory card into the PCI Express slot of the computer and connect the individual nodes by optical fiber

Software installation: Install the reflective memory card driver and configure the related parameters

Maintenance and upgrades: Provide field-upgradeable firmware to adapt to changing application requirements

In summary, the GE FANUC PCI-5565RC Reflective Memory Node card is a powerful, high-performance data sharing solution for a variety of distributed systems requiring high-speed, real-time data exchange.
